Material

SS 304/316

Measurements

Length

bespoke as requirement

Height

850-1200mm;Typically 1000mm;can be customized as request

Price vary according to the measurements & requirements

Top Handrail/Secondary Handrail

Stainless Steel

Φ 38/42/50mm slot pipe with gasket;304/316 brushed&polished

28*30mm square cap with gasket;304/316 brushed&polished

50*10mm flat handrail with bracket;304/316 brushed&polished

Standoff

Stainless Steel

Φ 25/38/42/50mm round;50*50mm square; brushed/polished

Glass Panel

Tempered Glass

10/12mm tempered glass

6+1.52+6mm laminated glass

Position

Balcony/Stair/Porch/Deck/Roof Top

MOQ

10m

Delivery

30-35 days upon receipt of the deposit&sign off shop drawing

Installation

DIY installation, no welding work needed; just screws

Installation structions will be provided if needed

Please Note:

1. All specifications are for reference purposes only. Dimensions for guide only. Component may vary slightly from the sizes shown.

2.Customers are encouraged to ask their local city to get information about their local building codes. City building codes supersede national building codes. We provide the information in an advisory capacity only and is not liable for any code non-compliance.
